Rigid PCB Manufacturing
Optimizing PCB Cost & Reliability
Low-cost with product-reliable PCB Manufacturing aims to look at the design or product from a printed circuit board manufacturer's perspective. What this means is that you need to understand, as a designer or a buyer, the true PCB complexity, the number of manufacturing processes & the equipment set required to get the product done with the highest yields at the best possible price. Picking the correct solution or vendor is getting increasingly complex because of the diverse technology mix in any product or system. The most cost-effective manufacturing solution is to split up the builds based on technology among two or even three PCB manufacturers for maximum cost and efficiency. This can be challenging if the manufacturing solution isn't appropriately developed and managed in real-time for success. Tech-Driven EMS's 25 years of knowledge and experience working with these vendors will ensure product-to-market success at the lowest possible cost.
Micro Chip Sets We Support
- Ball Grid Arrays “BGA"
- Flip Chip
- Pin Grid Arrays “PGA"
- Land Grid Array “LGA”
- Ceramic Column Grid Array “CCGA”O
Surface Finishes
- ENIG (Gold Immersion)
- ENEPIG (Wire Bonding)
- OSP (Organic Coating)
- Tin Immersion
- HASL (Hot Air Level)
- Tin-Lead (60/40)
- Silver immersion
- Hard Gold (Flash Selective)
- Soft Gold (Wire Bonding)
Standard Materials
- High-Temp FR2
- High-Temp FR4
- 370 HR Halogen Free
- FR408HR
- Polyimide
- Flex
- DuPont
- AP
- All offshore equivalents
Advanced Multilayer PCB Manufacturing
Pro-active full DFM Support
Today's Printed Circuit Board is now the differential item controlling the critical functionality of the product's overall performance. As products become more advanced, HDI (high-density interconnects). With speeds moving past 60 gigahertz and BGAs (Ball Grid Array) with 2100 IOs. The Pcb becomes the most critical attribute. Today's advanced Printed Circuit Boards must have controlled speeds that perform consistently for best product performance. This is why we support seamless prototyping, high mix to low volume, and volume-printed circuit boards domestically and offshore.
Advanced PCB Capabilities
- Fine Line/Spacing .001" (25Microns)
- Print and etch with Selective Plate (HDI)
- Multilayer (2-70)
- High Aspect ratio 30:1
- Multilayer Flexible Circuits
- Multiple Laminations
- Thin Core Flex Materials
- Book Binder Flex
- Controlled Impedance (5%)
- Heavy Copper (12oz)
- PTFE RFMW
- Cavity Boards
- Micro Via's
- Drilled Laser Drilled Microvia’s .002"
- Via-in-Pad (4 mil Drill)
- Solid Copper Filled Vias (18 Mils)
- Stacked MicroVia's (12)
- Blind & Buried Via's (7)
- Anywhere Via Technology
- Castellations
- Heatsinks
- Metal Core
- Burn-in-Boards
- Probe Cards
- Fusion Bond Lamination
- Custom Cores
- Via anyWhere
- Wrap plating requirements
- Ormit Paste
- Epoxy Fill (conductive & Non-conductive)
- Laser-modified controlled depth drill
- NextGen-SMVTM
- 70 Material types
Advanced Chip Sets
Laser Direct Imaging
Netlist Fying Probe testing
High-Reliability Space & Military
Tech Driven's services provide customers with a plan to improve quality and reliably on every build.
Certifications / Registration:
MIL-PRF-31032 Space Addendum
MIL-PRF-55110 IPC-J-STD-001
ISO 9001-2008 IPC -791
AS9100C ITAR
UL-94-VO, DSR
IPC-6012A Class 3 (DS)
Quick-Turn Assembly as fast as 1 to 3 days
Now that we have explained our support and services for low, medium, and highly advanced printed circuit boards for Rigid, Rigid-flex, and Flex, Let us also support your extremely fast, demanding, quick-turn PCB Assembly requirements. We can buy parts and build complete assemblies in as fast as 1 to 3 days.
Customer Satisfaction
"I do so much PCB assembly, but setting up and supporting quick turn small quantity builds is never easy or profitable for our organization. Tech Driven and its partners seem to want, understand, and have created an efficient model that seems to be consistent & dependable. I use them for all my Quick turn PCB assembly needs."
Samuel Pete
Flash Assembly
